Model: SATA185X
Features:
1. Full aluminum alloy enclosure, excellent heat dissipation.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt 5 wires resistive touch screen, high precision, durable, anti-interference.
4. High performance motherboard, 7x24 continuous operation.
5. Support wall mounting, rackmount and etc. apply to a wide range of industrial application.
6. With 8 USB.
| PC | |
| CPU | Intel® Celeron J1900, quad core, 2.0GHz, fanless |
| Chipset | Intel ValleyView SSA-CUnit |
| Memory | 8G DDR3 |
| Hard Drive Capacity | 500G HDD |
| Hard Drive Optional | SSD: 64GB, 128GB, 256GB, 512GB, 1TB |
| HDD: 1TB, 2TB | |
| Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
| Audio | Realtek® High Definition Audio Decoder (5.1) Digital audio via HDMI Port |
| Network | 2x Realtek® Gigabit Ethernet Controller(RTL8111F) |
| Wireless Network | WIFI |
| I/O Interface | 6×USB2.0, 2×USB3.0, 2xCOM RS232, 2×LAN |
| 1×VGA/HDMI/Audio OUT/MIC IN/POWER DC | |
| Opetation System | Windows7/8/10, Ubuntu/Debian/Fedora/Redhat and etc |
| LCD panel | |
| Panel size | 18.5" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness | 450 cd/m² |
| Response time | 3ms |
| Contrast ratio | 1000:1 |
| View angle | 85°/85°/80°/80° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 5 wires Resistive touch |
| Touch Interface | USB (RS232 Optional) |
| Touch response time | <8ms |
| Luminousness | 75-85% |
| Surface Hardness | 3H |
| Working Life | >35 million times |
| Touch options | (Capacitive touch, non touch Optional) |
| VESA mounting | 100×100 mm |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V |
| Power consumption | ≤50W |
| Enclosure | |
| Material | Aluminum Alloy |
| Color | Silver, Black, white, color can customize |
| VESA mounting | 100×100mm |
| IP grade | Front panel IP65 waterproof |
| Operating Environment | |
| Temperature Range | Operating: -10 to 60°C, storage :-20 to 80°C |
| Relative humidity | 5%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Packing Details | |
| Net weight | 5kgs |
| Gross weight | 7kgs |
| Product Dimension | 46×28.4×5.7cm |
| Packing size | 57×41×16cm |
| Accessories | Power adapter,power cord WIFI antenna, warranty card |
| Other | |
| Mounting (options) | 1) Provide wall brackets for wall-mounting, VESA 100×100mm |
| 2) Provide stable metal holder to support the monitor | |
| Warranty | 1 year warranty |
| Certificate | CE, FCC, RoHS |
