Model: SATA22X
Features:
1. Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof and dustproof.
2. Industrial LCD panel, wide viewing angle, 1000cd/m² sunlight readable, dimming via buttons.
3. Adopt multi-points PCAP touch panel, high sensitive and fast-response.
4. High performance motherboard, 7x24 continuous operation.
5. Support wall mounting, embedded mounting, desk stand mouting etc.
6. Built-in microphone.
| PC | |
| CPU | Intel® Celeron 3865U, dual-core, 1.8GHz. Fanless |
| Chipset | SOC |
| Memory | 4G DDR3 (Max.16G) |
| Hard Drive Capacity | 64G SSD |
| Hard Drive Optional | SSD: 128GB, 256GB, 512GB |
| HDD: 500GB,1TB | |
| Graphics | Intel HD Graphics 510, support 4K |
| Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
| Network | 2×Realtek RTL 8111E Gigabit Ethernet controller |
| Wireless Network | WIFI(Optional) |
| I/O Interface | 2xUSB 2.0, 2xUSB 3.0, 2xCOM RS232 |
| 1×VGA/HDMI/RJ45/Audio OUT/MIC IN/POWER DC | |
| Operation System | Support Windows 7/8/10, Ubuntu, Debian, Fedora and etc. |
| Microphone | 1×Built-in microphone |
| LCD panel | |
| Panel size | 21.5" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 1000 cd/m², sunlight readable |
| Response time | 5ms |
| Contrast ratio | 1000:1 |
| View angle | 89°/89°/89°/89° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | Project Capacitive Touch (10 points) |
| Touch Interface | USB (RS232 Optional) |
| Touch response time | 2ms |
| Luminousness | 90% |
| Surface Hardness | 7H |
| Working life | >50 million times |
| Touch options | ( 5 wires Resistive touch, non touch Optional) |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Aluminum Alloy+high strong rolled steel |
| Color | Silver, Black, White, color can customize |
| VESA mounting | 75×75mm/100×100mm |
| IP grade | Front panel IP65 waterproof and dustproof |
| Operating Environment | |
| Temperature Range | Operating: -20 to 70°C, storage: -20 to 80°C |
| Relative humidity | 5%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Packing Details | |
| Net weight | 6.7kgs |
| Gross weight | 8.1kgs |
| Product Dimension | 53.76×31.99×4.3 cm |
| Packing size | 69×55×20 cm |
| Accessories | Power adapter, embedded screws, user manual, warranty card |
| Other | |
| Mounting (options) | Open frame |
| Embedded mounting screws (Optional) | |
| Wall mounting brackets (Optional) | |
| Desk stand holder (Optional) | |
| Warranty | 1 year warranty |
| Certificates | CE, FCC, RoHS |
