Features:
1. IP65 sealed stainless steel enclosure, Sealed I/O cables included.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt 5 wires resistive touch screen, high precision, durable, anti-interference. Support touch with glove.
4. High performance motherboard, 7x24 continuous operation.
5. Fully sealed and fanless design, Full IP65 waterproof.
| PC | |
| CPU | Intel® Celeron J1900, quad core, 2.0GHz, fanless |
| Memory | 4GB DDR3 (8GB Optional) |
| Hard Drive Capacity | 64GB SSD |
| Hard Drive Optional | SSD: 128GB, 256GB, 512GB |
| HDD: 500GB,1TB | |
| Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
| Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
| Network | Onboard Realtek RTL 8111E Gigabit Ethernet controller |
| Wireless Network | WIFI Optional |
| I/O Interface | 4*USB+1*LAN+1*DC |
| Operation System | Support Windows 7/8/10, Linux, Ubuntu, Debian etc. |
| LCD panel | |
| Panel size | 21.5" |
| Resolution | 1920*1080 |
| Aspect ratio | 16:9 |
| Support Color | 16.7M colors |
| Brightness (cd/m²) | 400 nits |
| Response time | 5ms |
| Contrast ratio | 1000:1 |
| View angle | 80°/80°/80°/80° (R/L/U/D) |
| Touch panel | |
| Touchscreen Type | 5 wires resistive touch |
| Touch solution | EETI |
| Touch Interface | USB (RS232 Optional) |
| Touch response time | <8ms |
| Luminousness | 90% |
| Surface Hardness | 3H |
| Working Life | >35 million times |
| Touch options | (Capacitive touch, IR touch Optional) |
| Power Supply | |
| External Power Supply | AC 100-240V |
| Working voltage | DC 12V (9-36V wide voltage Optional) |
| Power consumption | ≤45W |
| Enclosure | |
| Material | Stainless steel case 304 |
| Color | Silver |
| VESA mounting | 75x75mm/100x100mm |
| IP-grade | Full IP65 waterproof |
| Operating Environment | |
| Temperature Range | Operating: -20 to 70°C, storage: -20 to 80°C |
| Relative humidity | 5%~95% @ 40° C, non-condensing |
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| Packing Details | |
| Net weight | 8.5kgs |
| Gross weight | 12kgs |
| Product Dimension | 53.16x32.82x5.74cm |
| Packing size | 74x45x19 cm |
| Accessories | Power adapter, waterproof LAN/USB cable, power cord |
| Other | |
| Mounting (options) | 1) Wall bracket for wall-mounting, VESA 100x100mm |
| 2) Stable metal holder to support the pc | |
| Certificates | CE, FCC, RoHs |
| Warranty | 1 year warranty |
